★Size 1.8m*15mtr/20mtr/Any length
Thickness3.5mm/ 4.5mm/5.0mm/6.0mm/7.0mm/8.0mm
★Material 100% pure pvc material
Color Maple/ Oak/ Brown Wood/ Teak /Walnut
★Application Indoor Sports Court
Package Paper tube inside and waterproof kraft paper outside.
Advantages
Superior Comfort,Protection,Safely,High Performance to All Users
Protection
Jiandi flooring reduces the immediate injury risks to all users when falling,diving or sliding on the floor.Jiandi floor surface minimises the risk of friction burns.The floor provides safe grip and resistance as the athlete accelerates and manoeuvres allowing for full freedom of movement.
Safety
Provides better shock absorption minimizing the force of impact on the body . . Comfort
Provides perfect bounce for all ball sports and gives a comfortable feeling underfoot with Jiandi floor High Density Foam.
High performance.
Provides supeior bounce,good vertical deformation,better shock absorption and sliding resitance,which ensures high performance.
| Technical Data | |||
| Standard | Unit | Basketball | |
| Description | |||
| Roll length | /// | m | 15/20 |
| Roll Width | /// | m | 1.8 |
| Total thickness | /// | mm | 4.5-8.0 |
| Wear Layer | /// | mm | 0.7 |
| Weight | /// | g/m2 | 3600/6700 |
| Sport Characteristics | |||
| Hardness | /// | HD | 120 |
| Rebound Value | /// | % | 9 |
| Shock absorption | DIN18032 | % | ≥28 |
| friction coefficient | DIN18032 | /// | 0.45 |
| ball bounce | DIN18032 | % | ≥97 |
| Technical Characteristics | |||
| indentation resistance | EN1516 | mm | ≤0.6 |
| abrasion resistance | EN ISO5470-1 | mg | ≤300 |
| impact resistance | DIN18032 | N/M | ≥8 |
| sound insulation | EN ISO5470-2 | db | 19 |
